10x10 Loafing Shed (3 Walls)

10x10 Loafing Shed (3 Walls)

$1,449.95

Note: Select if you want bare metal/rustic or powder coated finish

Color: Powder Coated - Dapple Grey





 DIY 10x10 Loafing Shed Kit

Finally, an easier and more affordable option to keep your horse out of the rain or harsh sun is here. Our shelter kits are engineered to be an easy DIY installation process that anyone can do. No need to hire an expensive metal fabricator to come to your property to custom build your stall. Just clamp the panels, gate, and trusses together. Then, fasten the roof material sheets to the tops of the trusses.

Made from heavy duty 14 gauge steel.

3-Sided 10x10 Loafing Shed Details:

  • 14-Gauge Steel
  • 10ft wide
  • 10ft long
  • 10ft tall in the front
  • 8ft tall in the back
  • Expert Welds
  • Choose bare metal or powder coated
  • Easy to setup, just clamp everything together
  • Proudly Made in USA!


KIT Includes:

  • (3) Shelter Panels
  • (3) 10ft Z Purlin Trusses
  • (4) 10ft PBR Roof Material
  • (6) Panel Clamps with Hardware
  • (4) Ground Posts with Hardware
  • (1) Pack Self Tapping Screws with Rubber Washers
  • Wood NOT included

The bare metal panels will get the same patina/surface rust as the oil pipes that all working ranches use. If you don't want the rustic-look, then go with our powder coated option.

CLASS C POWDER COATING

Durable and cost-effective finish though not as strong as Class A. Minor scratches, chips, and blemishes are common. Additional scratches can occur during transit, touch-up paint available if needed.

*STRUCTURES ARE PORTABLE AND SELF STANDING - NOT INTENDED FOR ANY OTHER USE.
* THESE SHADE KITS ARE NOT ENGINEERED STRUCTURES AND DO NOT MEET ANY SPECIFIC BUILDING CODE CRITERIA. PLEASE, CHECK YOUR LOCAL BUILDING CODES BEFORE ORDERING.

How To Place An Order

Contact us by phone, email, or live chat to place your order. Delivery fee depends on location and mileage. Or, come pick up from our yard near Norco, California.
